Auto Bag Inserter [GPK-40T]
Description
This machine adopts the servo control, it can be connected to the front automatic carton erector, and the rear automatic cartoning machine realizes unmanned automatic packaging. The automatic bag inserter GPK-40T can automatically complete the carton input, positioning, film output, back cover, box entry, film cutting, sides folding, and carton output. Applicable to food, solid oil, oil, edible oil, condiments, biscuits, snack foods, bulk food, raw materials, beverages, chemicals, hardware, screws, electronics, rubber, plastic, plastic and other carton bagging.
Features
- High Applicability: it can be combined with the carton erectors and different packaging equipments, and is suitable for various packaging methods.
- Bagging accurately: the way of entering the carton can be divided into the upper part, the bottom part.
- Simple operation: stable performance and easy adjustment.
- Better protect the products in cartons: the advantage of the bag inserting is that it can protect the product, avoid product moisture, wetting and other factors affecting product quality.
Specification
| Folding Speed | 8-10pcs/min |
| Carton Size | L250-500×W200-400×H150-400mm (L≥W+100mm) |
| Power Supply | 380V 50Hz 3Phaze |
| Power | 3.5KW |
| Air Consumption | 50NL/mm |
| Air Compressing | 4-7kg/cm³ |
| Table Height | 600mm |
| Machine Dimension | L2000×W1600×H1900mm |
| Machine Weight | 700kg |
